High/Half Height Roof Cab, tilt cab
|
Drive mode
|
HFC5315KR1
|
|
Driving Mode
|
8X4
|
|
Cabin Model
|
N944 HALF HEIGHT
|
|
|
|
|
|
Engine
|
Model
|
WD12.375
|
|
DisoIacement(ccJ)
|
11596
|
|
Max output power(Hp/rpm)
|
375/2200
|
|
Max to roue N m/rpm)
|
1500/1300-1600
|
|
|
|
|
|
Transmission
|
Model
|
10JSD160T
|
|
Gear ratio
|
14.86/1.00
|
|
Gear positon
|
R2/R1 7/2 9/4 6/1 8/3 10/5
|
|
|
|
|
|
Clutch
|
Mode
|
Single, dry plate, diaphragm spring, VALEO
|
|
|
|
|
|
Rear Axle
|
Model
|
Steyr Technoloqy
|
|
|
Rear Axle Ratio
|
4.8
|
|
|
|
|
|
Main parameter
|
Front Axle Capacity (ton)
|
6.5X2
|
|
Rear Axle Capacity Eton)
|
13x2
|
|
Overall Dimension(mm)
|
8680X2500X3905
|
|
Wheel base(mm)
|
1800+3200+ 1350
|
|
Tread(mm)
|
2040/1864
|
|
FF/AF(MM)
|
1495/2485
|
|
Curb weight(Kg)
|
14700
|
|
Rated payload(Kg)
|
26300
|
|
GVW(Kg)
|
41000
|
|
Max speed ‹Km/h)
|
86
|
|
Radius of turning(m)
|
<11
|
|
|
|
|
|
Mixing Tank
|
(M3)
|
10
|
|
Tire
|
Model
|
315/80R22.5
|
|
Steering system
|
Type
|
ZF Steering gear
|
|
Brake system
|
Mode
|
Dual-circuit air brake
|
|
|
|
|
|
Other
|
Conditioner
|
Standard
|
|
Electric glass
|
Standard
|
|
ABS
|
Standard
|
