Item
|
Unit
|
Parameter
|
|
Max. lifting capacity
|
Main Boom
|
t
|
280
|
|
Fixed jib
|
t
|
37
|
|
Boom Single top
|
t
|
78
|
|
Max. load moment
|
kN-m
|
15000
|
|
Boom length
|
m
|
18～87
|
|
Boom elevating angle
|
°
|
12~36
|
|
Fixed jib length
|
m
|
27～60
|
|
Boom luffing angle
|
(°)
|
3~84
|
|
Max. single line speed (at 6th layer with no load)
|
m/min
|
137
|
|
Boom luffing gear max. single line speed(at 1st layer)
|
m/min
|
2x27
|
|
Max rope single line pull
|
t
|
15
|
|
Wire rope diam
|
mm
|
26
|
|
Max. Slewing speed
|
rpm
|
1.3
|
|
Max. Traveling speed
|
km/h
|
1.1
|
|
grade ability
|
%
|
30
|
|
Mean ground pressure
|
Mpa
|
0.12
|
|
Engine output power
|
kW
|
242
|
|
Gross vehicle mass (main hook block, 18m boom)
|
t
|
252
|
|
Max. weight of single unit in travel configuration
|
t
|
58.0
|
|
Max. dimension of single unit(basic machine) in travel configuration (LxWxH)
|
m
|
12.53x3.47x3.46
|
